2025 Husqvarna 135 Mark II
OVERVIEW
Availability: Brochure
Year: 2025
Make: Husqvarna
Model: 135 Mark II
PRODUCT DESCRIPTION
Easy-to-use and powerful chainsaw for homeowners and light professional use. Designed with Smart Start® and LowVib® technology, it delivers comfort, efficiency, and reliable performance. The X-TORQ® engine ensures superior power, fuel efficiency, and low emissions, while Air Injection™ protects engine life.
Features
Powerful X-TORQ® Engine: High power and efficient fuel usage
LowVib® Technology: Reduces vibrations for comfortable use
Smart Start® Technology: Engine and starter designed for easy, fast starting
Quick Start with Air Purge: Removes air from carburetor and fuel system for effortless starts
Simple Starting: Stop switch automatically resets to ON
Air Injection™ Technology: Expels larger dust and debris for longer engine life
Combined Choke/Stop Control: Easier starting and prevents engine flooding
Inertia-Activated Chain Brake: Reduces risk of kickback injury
Side Chain Tensioning: Quick and convenient chain adjustment
Engine
Chain speed at max power: 55 fts (16.8 m/s)
Cylinder displacement: 38 cm³
Output shaft power: 2.1 hp (1.6 kW)
Torque, max.: 1.84 Nm at 8,000 rpm
Clutch engagement speed (±120): 4,000 rpm
Electrode gap: 0.022 in
Idling speed: 3,000 rpm
Ignition module air gap: 0.012 in
Maximum power speed: 9,000 rpm
Oil pump type: Automatic
Spark Plug: NGK BPMR7A
Equipment
Recommended bar length, min: 14 in (35 cm)
Recommended bar length, max: 16 in (40 cm)
Bar length: 16 in (40 cm)
Pitch: 3/8" mini
Chain type: S93G
Sprocket type: Spur 6
Gauge: .050"
Dimensions
Weight (excl. cutting equipment): 4.7 kg
Sound and Noise
Sound pressure level at operator’s ear: 102 dB(A)
Sound power level, measured: 114.34 dB(A)
Sound power level, guaranteed (LWA): 116 dB(A)
Vibration
Rear handle: 5.5 m/s²
Front handle: 3.72 m/s²
Lubricant
Oil tank volume: 0.549 US pint
Lubricant type: Husqvarna 2-stroke or equivalent at 50:1
Emission
CO2 EU V: 804 g/kWh
