2025 Great Plains 1006NT

Ideal for food plots to feed production, the 1006NT Drill combines the productivity of a large drill with the versatility of a compact design. This 10 ft. end wheel no-till drill is well suited for pasture renovations and food plots. The 1006NT has long been trusted by farmers and cattlemen, conservation groups such as Pheasants Forever and NRCS for rental programs, and roadside contractors who need a durable, easy-to-operate machine. The 1006NT Drill features large end wheels designed for excellent ground gauging in rugged terrain. Inline end wheels minimize sideloading on contours and side hills, dramatically extending the life of the no-till openers. Additional features include 4-speed gearboxes, a mechanical clutch that disengages when the drill is lifted, and rain-tight lids for maximum seed and fertilizer protection. Multiple box options provide exceptional versatility. Features 06 Series Opener: Utilizes the “Fluff and Plant” no-till system with an integrally mounted coulter to cut residue and prepare a mini seedbed for the trailing double-disc opener. Opener discs are 13.5 in. in diameter and 4 mm thick with 205 triple-lip sealed bearings and 1/4 in. opener disc lead. A full-length seed tube and trailing flap control seed placement to the bottom of the trench. Fluted Seed Cups: 1 3/4 in. powdered metal fluted seed cups deliver outstanding accuracy across a wide range of seed types. Folding Tongue: Reduces storage and transport space requirements (approximately 40 in.). Lock-Out Hubs: Disengage drive components to reduce wear during transport. Standard Weight Brackets: Accept standard tractor weights for improved penetration in tough no-till conditions. Versatile Box Combinations: Allows seeding of up to three different seed types simultaneously (main seed box, native grass box, small seeds box). 4-Speed Gearbox: Permanently lubricated and sealed gearboxes make seed rate changes quick and easy. Calibration Crank: Simplifies accurate seed rate calibration. End Wheel Design: Large end wheels maintain accurate seed placement on side hills and uneven terrain. Greatplainsag Mobile App: Provides step-by-step calibration assistance, manuals, specifications, and maintenance guides. Lead Coulter Options: Choose between a 3/4 in. wavy coulter, 5/8 in. Turbo coulter, or 5/16 in. fluted coulter for varying tillage needs. Press Wheel Options: Available options include double rib, center rib, smooth, double-V, or wedge-style press wheels to properly close the seed trench. T-Handle Opener Depth Adjustment: Offers 18 positions for precise seed depth control. Optional Fertilizer Box: Features easy cleanout and six-point meter wheels for accurate fertilizer application. Optional Second (Dual) Seed Box: Increases seeding efficiency and versatility. Specifications Model: 1006NT Primary Design: End Wheel No-Till Row Spacing: 7.5 in. (19.05 cm) Number of Openers: 15 Tire Size: 9.00 x 24, 8-ply Engine HP Requirements: 75+ HP Weight (Approx.): 4,300 lb. (2,041 kg) Working Width: 10 ft. (3.05 m) Width: 12 ft. 7 in. (3.84 m) Transport Length: 13 ft. 10 in. (4.22 m) Transport Clearance: 13.5 in. (34.29 cm) Transport Height: 6 ft. 7 in. (2.0 m) Opener Series: 06 Series Opener Travel: 6.5 in. (16.51 cm) Opener Depth Range: 0–3.5 in. (0–8.89 cm) Opener Down Pressure: 90–180 lb. (40.82–81.64 kg) Coulter: 5/8 in. Turbo or 5/16 in. Fluted Coulter Pre-Load: 450 lb. (203 kg) Main Box Capacity: 23.75 bu. Small Seed Box Capacity: 2.4 bu. Native Grass Box Capacity: 10 bu. Fertilizer Capacity: 9.2 cu. ft. Second Main Box Capacity: 10 bu. General Seed Box Capacity: 2.4 bu. Empty Weight: 4,300 lb. (2,041 kg) Dimensions Length: 13 ft. 10 in. (4.22 m) Width: 12 ft. 7 in. (3.84 m) Height: 6 ft. 7 in. (2.0 m)
